AC/DC:0-5/10KV, AC:20mA, DC:10mA Voltage Withstand Test Instrument

Measurement & Analysis Instruments > Safety Instrument
Include ISO 17025 CNAS & ILAC Calibration Certificate
Origin: China Guangdong
Item No.: RK2671AM

AC/DC:0-5/10KV, AC:20mA, DC:10mA Voltage Withstand Test Instrument


Operation condition:
Environment Temperature: 0~40°C
Relative Humidity: ≤75%
Atmospheric Pressure: 101.25KPa

Technical Index:

Item RK2671AM
Output   Voltage Range (AC/DC) 0   ~ 5 KV / 10 KV
Voltage   Resolution 10V
Voltage   Accuracy ±5%
Leakage   current (AC) 0-2/20mA
Leakage   current (DC) 0-2/10mA
Current   Resolution 0~2mA:1μA
2~20mA:10μA
Current   Accuracy ±5%
Measurement   Time Setting 0s-99s,Continuously   setting and manual
Maximum   output power 200VA
Capacitor   of Transformer 750VA
Display   Form LED   Digital Display
Power   Requirements 220V±10%,   50Hz±5%
Operation   Environment 0℃~40℃, ≤85%RH
Dimensions 300*370*200mm
Weight 14kg
